SB ACOUSTICS 15 SUB-WOOFER - FHCL
HONEYCOMB CONE LONG STROKE
SKU code: WES_SB42FHCL75-6_1
Most of our items are in stock and will be dispatched within 3 working days. In rare cases where an item needs to be sourced from our supplier, dispatch may take up to 7 working days.
AvailableThis is a SB ACOUSTICS 15 SUB-WOOFER - FHCL of brand SB Acoustics.
SALIN is a leading Australian appliance spare parts distributer . We take pride in our ability to bring hard to find appliance spare parts into the Australian market. We are proudly Australian owned and operated. Our warehouse and sales office is conveniently located in Auburn, NSW. Our range of spare parts are manufactured with premium components and quality material. Most of our range is directly sourced from manufacturers and geniune.
| TECHNICAL SHEET | |
|---|---|
| Title | SB ACOUSTICS 15 SUB-WOOFER - FHCL |
| Notes | HONEYCOMB CONE LONG STROKE Light weight rigid honeycomb cone (hard paper honeycomb with fibre glass skin layers). 75mm copper voice coil for improved power handling. Long life silver lead wires. Vented pole piece for minimum compression. Vented cast aluminium chassis for optimum strength and low compression. Low damping rubber surround for improved dynamic linearity. Non-conducting fibre glass voice coil former for minimum damping. Large motor system.Light weight rigid honeycomb cone (hard paper honeycomb with fiber glass skin layers)3 copper voice coil for improved power handlingLong life silver lead wiresVented pole piece for minimum compressionVented cast aluminium chassis for optimum strength and low compressionLow damping rubber surround for improved dynamic linearityNon-conducting fiber glass voice coil former for minimum damping Large motor system |
| Description | - |
| Type | Woofer |
| Size | 15' |
| Price Type | each |
| Power | 300Wrms |
| Coil | 75.6mmØ |
| Width | 417mmØ |
| QTY | 1 |
| Impedance | 6.0Ω (Re 4.0Ω) |
| Depth | 170.3mm |
| Mag. | 3.6kg |
| Sens. | 93dB |
| Re | 4.0Ω |
| Qms | 7.4 |
| Qes | 0.32 |
| Qts | 0.31 |
| Vas | 462L |
| Sd | 850cm² |
| Cms | 0.45mm/N |
| Fs | 18.4Hz |
| Mms | 166g |
| Zn | 2.1mH |
| Le | 2.1mH |
| Rms | 2.6kg/s |
| Diam. | 381mmØ |
| Series | Long Stroke |
| Manufacturer | SB Acoustics |
| Materials | Honeycomb |
| Impedance (Ohm) | 6 ohm |
| Power (RMS) | 200+ Watt |
| Inch | 15 |
| Bl | 16.7Tm |
| Xmax | 23mm |
| Flux (lm) | 1.1T |
| eBook | Link to eBook |
| Prms | 300W |
| Page | 36 |
| SKU No | WES_SB42FHCL75-6_1 |
