LARGE SERIES SOCKET PUSH LOCK
FRONT PANEL MOUNT - FEMALE PINS
SKU code: WES_24018635-01_1
This is a LARGE SERIES SOCKET PUSH LOCK of brand Chogori.
SALIN is a leading Australian appliance spare parts distributer . We take pride in our ability to bring hard to find appliance spare parts into the Australian market. We are proudly Australian owned and operated. Our warehouse and sales office is conveniently located in Auburn, NSW. Our range of spare parts are manufactured with premium components and quality material. Most of our range is directly sourced from manufacturers and geniune.
| TECHNICAL SHEET | |
|---|---|
| Title | LARGE SERIES SOCKET PUSH LOCK |
| Notes | FRONT PANEL MOUNT - FEMALE PINS This Large series connector is blue capped to indicate a different pin gender for use where the signal is in another direction to the yellow capped versions. Simple push to lock plug insertion, then twist and pull to release. Mounting screw is attached to the front of the chassis panel. Excellent mechanical properties of phosphor bronze assembly with good electrical conductivity brass. It is ideal for indoor and outdoor harsh working environments. The connector can insert and withdraw to 3000 times or more, ensure a reliable contact every time. Cap to suit: 804-00005-00 |
| Description | Large series 18pin front panel mount with socket(push lock) |
| Contact | 18 |
| Cable | 22AWG |
| Hole | 25mmØ |
| Wire Gauge | 0.3mm² |
| Panel Thickness | Max 5.0mm |
| IP | IP67 |
| Operating Temperature | -45 ~ +105 |
| Voltage Rating | 125V |
| Rated Current | 5A |
| Chogori Cat Page | 85 |
| Brand. | Chogori |
| Manufacturer | Chogori |
| SKU No | WES_24018635-01_1 |
