This is a LARGE SERIES INLINE PLUG PUSH LOCK of brand Chogori.

SALIN is a leading Australian appliance spare parts distributer . We take pride in our ability to bring hard to find appliance spare parts into the Australian market. We are proudly Australian owned and operated. Our warehouse and sales office is conveniently located in Auburn, NSW. Our range of spare parts are manufactured with premium components and quality material. Most of our range is directly sourced from manufacturers and geniune.

TECHNICAL SHEET
Title LARGE SERIES INLINE PLUG PUSH LOCK
Notes Series inline connector for extending Large Series Connectors.The push-locking connector is simple and fast to plug in and out. All the products are manufactured with high quality materials, the plastic material used is high performance PA66, male pin used is excellent mechanical properties of phosphor bronze assembly with good electrical conductivity brass. Products have certificate by CE, UL, TUV and ROHS environmental protection requirements. Large series connector has good performance in waterproofing. IP67.
DescriptionLarge series 9pin female connector with female pin field installable(push lock)
Cable18AWG
Cable Range6.5-10.5
Chogori Cat Page86
IPIP67
Contact9
Mechanical Life500 mating cycles
Operating Temperature-45 ~ +105
Rated Current5A
Size57x27mmØ
Voltage Rating125V
Wire Gauge0.75mm²
ManufacturerChogori
SKU NoWES_24009431-02_1



SALIN is not responsible for any possible damage caused by misselection and incorrect installation of the spare parts.

All electrical items must be fitted by a qualified electrician.

Errors and Omissions Excepted:

All information contained herein this website is assumed to be accurate, however, no responsibility is assumed by SALIN  for its use, nor for any infringements of patents or other rights of third parties which may result from its use.

Legal Disclaimer:

All trademarks, logos and principal representations remain the property of their respective owners. The use of brands, brand names and trademarks doesn't imply SALIN is representing those brands, companies, trademarks or names. SALIN holds no rights to products and/or services available or provided by the said companies, brands, brand names and trademarks.

MPN
SKU WES_24009431-02_1
Brand Chogori
