HDMI OVER HDBaseT EXTENDER 4K30 WITH 48V PoC & AUDIO - CYPRESS
UP TO 100M WITH IR, RS-232, 48V PoC, LAN, USB/KVM & ARC
SKU code: WES_CH-1601RX_1
This is a HDMI OVER HDBaseT EXTENDER 4K30 WITH 48V PoC & AUDIO - CYPRESS of brand Cypress.
SALIN is a leading Australian appliance spare parts distributer . We take pride in our ability to bring hard to find appliance spare parts into the Australian market. We are proudly Australian owned and operated. Our warehouse and sales office is conveniently located in Auburn, NSW. Our range of spare parts are manufactured with premium components and quality material. Most of our range is directly sourced from manufacturers and geniune.
| TECHNICAL SHEET | |
|---|---|
| Title | HDMI OVER HDBaseT EXTENDER 4K30 WITH 48V PoC & AUDIO - CYPRESS |
| Notes | UP TO 100M WITH IR, RS-232, 48V PoC, LAN, USB/KVM & ARC Send uncompressed digital audio and video along with control, IP and USB data, RS232 and Ethernet over a single run of CAT5e/6/7 cable up to 100m (1080p). Uniquely, there is a bi-directional digital audio capability that gives users the convenience of an additional digital audio connection. This system also allows the connection of any USB host, enabling a USB connection to up to 2 USB ports, giving the Receiver the ability to act like a USB hub. The 48V PoC design can power the Receiver (PD) from the Transmitter (PSE), eliminating the need for a separate power supply for the Receiver.Supports HDBaseT 2.0 specification over a single CAT5e/6/7 cable up to 100m/328ftFully compliant with HDMI 1.4, and compatible with HDMI 2.0 (4K2K 60Hz with 4:2:0)Receiver features 2 USB 2.0 portsHDMI (with 3D & 4K2K support), HDCP and DVI compliantHDBaseT 5Play™ convergence: High-Definition Video and Audio, 100BaseT Ethernet, PoC and Control (Bidirectional IR/RS-232 pass-through)Supports pass-through of audio formats: LPCM 2/5.1/7.1CH, Dolby® Digital 2~5.1CH, DTS 2~5.1CH, Dolby® Digital Plus, Dolby® TrueHD and DTS-HD Master AudioSupports 100Mbps Ethernet capabilitiesBidirectional LAN and external digital audio capability |
| Description | HDBaseT HDMI Receiver over CAT5/6/7 with 48V PoE |
| Type | Receiver |
| Input | 1x CAT5e/6/7 |
| Output | 1x HDMI |
| IR | Yes |
| Cable Length | 100M (@ 1080p) |
| 3D | Yes |
| HDCP | Yes |
| PoE | Yes |
| Ethernet | Yes |
| HD Audio | Yes |
| 4K | Yes |
| RS-232 | Yes |
| Max Res. | 4K @ 30Hz |
| Compatible with | CH-1601TX |
| Extender Cable | CAT5e/6/7 |
| Manufacturer | Cypress |
| SKU No | WES_CH-1601RX_1 |
SALIN is not responsible for any possible damage caused by misselection and incorrect installation of the spare parts.
All electrical items must be fitted by a qualified electrician.
Errors and Omissions Excepted:
All information contained herein this website is assumed to be accurate, however, no responsibility is assumed by SALIN for its use, nor for any infringements of patents or other rights of third parties which may result from its use.
Legal Disclaimer:
All trademarks, logos and principal representations remain the property of their respective owners. The use of brands, brand names and trademarks doesn't imply SALIN is representing those brands, companies, trademarks or names. SALIN holds no rights to products and/or services available or provided by the said companies, brands, brand names and trademarks.
| MPN | |
| SKU | WES_CH-1601RX_1 |
| Brand | Cypress |
