This is a CAT5 EXTENDER REDBACK - PA4928 RECEIVER of brand Redback.

SALIN is a leading Australian appliance spare parts distributer . We take pride in our ability to bring hard to find appliance spare parts into the Australian market. We are proudly Australian owned and operated. Our warehouse and sales office is conveniently located in Auburn, NSW. Our range of spare parts are manufactured with premium components and quality material. Most of our range is directly sourced from manufacturers and geniune.

TECHNICAL SHEET
Title CAT5 EXTENDER REDBACK - PA4928 RECEIVER
Notes AUSTRALIAN MADE This single output microphone/line hub is designed to accept audio from a preamp wallplate (PA4931) or box (PA4932). Accepts either a microphone or line input and converts the signal to a balanced high level output. The 3V output signal is carried via Cat5e cable, (suitable for distribution up to 300m without interference) back to this hub. Wallplate microphone input is via a balanced XLR whilst the line input is via 2 x RCA sockets or 3.5mm audio jack for portable devices with a lower level line output.The PA4928 hub has a dedicated balanced or unbalanced output, with volume control. Output has DIP switch selectable balanced mic/line, or unbalanced line level output which can be fed directly into amplifiers. Powered by 24V DC from the supplied plugpack.The Redback CAT5 Extender series is designed to send and receive audio over CAT5 cable up to a maximum distance of 300 metres. An installation requires one receiver PA4928 and your choice of sender being a PA4932 unit or wall plate style options PA4931 (Horizontal) or PA4931V (Vertical), all sold separate. The input to output is either a balanced microphone XLR, or line level stereo audio via RCA or 3.5mm. The receiver includes a mains power pack and phantom powers the senders via the CAT5 cable. These units are of premium quality and performance and made in Australia by Redback.Connects to PA4931/ PA4931V Microphone/Line Pre-Amplifer Zone Wallplate or PA4932 Zone Preamp Box.Easy Cat5e/6 UTP data cabling connection.Up to 300m cable runs out to wallplate/box.Balanced Euro terminal block connections.Balanced mic or line level operation.24V DC operation.Australian designed & assembled.
ManufacturerRedback
SKU NoWES_PA4928_1



SALIN is not responsible for any possible damage caused by misselection and incorrect installation of the spare parts.

All electrical items must be fitted by a qualified electrician.

Errors and Omissions Excepted:

All information contained herein this website is assumed to be accurate, however, no responsibility is assumed by SALIN  for its use, nor for any infringements of patents or other rights of third parties which may result from its use.

Legal Disclaimer:

All trademarks, logos and principal representations remain the property of their respective owners. The use of brands, brand names and trademarks doesn't imply SALIN is representing those brands, companies, trademarks or names. SALIN holds no rights to products and/or services available or provided by the said companies, brands, brand names and trademarks.

MPN
SKU WES_PA4928_1
Brand Redback
