3G/4G/5G CEILING ANTENNA 698-6000MHZ
WIDE BAND 670MHZ TO 6000MHZ
SKU code: WES_ANT713_2
This is a 3G/4G/5G CEILING ANTENNA 698-6000MHZ of brand Benelec.
SALIN is a leading Australian appliance spare parts distributer . We take pride in our ability to bring hard to find appliance spare parts into the Australian market. We are proudly Australian owned and operated. Our warehouse and sales office is conveniently located in Auburn, NSW. Our range of spare parts are manufactured with premium components and quality material. Most of our range is directly sourced from manufacturers and geniune.
TECHNICAL SHEET | |
---|---|
Title | 3G/4G/5G CEILING ANTENNA 698-6000MHZ |
Notes | WIDE BAND 670MHZ TO 6000MHZ The ANT713 is an economical, compact, high gain antenna suited for use in the bands 698-960 & ~1710-6000MHz. It comes standard with N socket on coax tail & is designed to be mounted in a non-metallic ceiling. It is small, unobtrusive & designed to be Low PIM, Low VSWR and DC Grounded. Excellent fixed solutions suited for use in the cellular bands GSM / CDMA / PCS / CDMA2000 / WCDMA / TD-SCDMA / TD-LTE / FDD-LTE /WiFi 2.4/5.8GHz bands. Indoor Signal Coverage.Compact 18x213mmØ4.8dBi 698-960MHz5.0dBi 1710-2170MHz6.3dBi 2300-2700MHz4.6dBi 3300-3800MHz6.3dBi 4900-6000MHzLow-loss tail to N Female |
Benelec | 024513 |
Freq. | 698-960MHz and 1710-6000MHz |
Gain | 4.5-6.3dBi |
Type | 4G / WiFi |
Plug | N Female |
Colour | White |
Dimensions | 18x213mmØ |
Impedance | 50 ohm nom. |
Termination | N Female |
Manufacturer | Benelec |
SKU No | WES_ANT713_2 |
